Cable Test Interface Fixture rated to 2100 Vdc
12 January 2026 - CAMI Research, manufacturer of the CableEye automation-ready cable and harness test system, has released an HV-rated test interface board that can be customized with LIF test blocks and any number of panel- and/or cable-mounted connectors not exceeding a total of 128 pins. First introduced thirty years ago, this line of generic boards has earned a reputation among test engineers worldwide as a reliable workhorse for demanding test interfaces. The CB60 continues this legacy, combining durability with flexible configuration options for higher pin counts and test voltages.
The CB60 generic custom interface board accepts a wide range of circular or other connectors and accommodates LIF test blocks and bulkhead and/or cable-mounted mating connectors. While a bulkhead connector mounted directly to the board produces a more compact interface, a cable-mounted solution would be preferred if the test cable consists of heavy-gauge wire or is bulky. Any panel-mount circular connector with four mounting holes fits the “X”-pattern slots. Total pin count cannot exceed 128.
Sold as a set of two boards, each test board may be paired with other CableEye adapter boards to accommodate any combination of connectors. Incredibly versatile, CableEye testers are expandable to accommodate large and complex harnesses, and users can connect and configure them in numerous ways — set up an array of QuickMount Housings fitted with connector boards, plug custom interface cables directly into any of the 64 pin headers on the control and expansion modules, or use a test interface panel, perhaps on a rack-mounted system. Not just a tester, a CableEye test system is a complete cable management system offering features not available on any other cable test equipment, and may be used to test unlimited types of connectors.
Available immediately, the CB60 (Item 781) requires a 256 TP tester. Rated to 2100 Vdc/ 1200Vac. Customization service is available.
