Cable Tester with advanced Automation Control
24 June 2025 - Combined Test Solutions unveiled the Cirris 5150 Cable Tester & Automation Controller—a ground-breaking solution that’s redefining the landscape of cable and harness testing. This isn’t just a tester; it’s a comprehensive powerhouse designed to elevate manufacturing processes with unparalleled precision and efficiency. The Cirris 5150 seamlessly combines high-voltage cable testing capabilities with advanced automation control. Whether you’re dealing with simple assemblies or complex harnesses, the 5150 adapts effortlessly, ensuring your testing processes are both robust and streamlined.
Equipped with Cirris High-Speed Test Points, the 5150 delivers rapid low-voltage testing without compromising accuracy. Its high-voltage testing capabilities — up to 1500 VDC and 1070 VAC — ensure comprehensive insulation resistance and dielectric withstand assessments, critical for maintaining product integrity.
Designed with modern manufacturing in mind, the 5150 supports a range of communication protocols, including ProfiNET, Ethernet/IP, Modbus, and OPC-UA. This ensures effortless integration into existing PLC systems, allowing for synchronized operations and real-time data exchange across your production line.
Modular Design
Downtime is minimized thanks to the 5150’s modular architecture. Each test point and functional card features LED indicators for swift diagnostics, and modules can be replaced or upgraded with ease, keeping your operations running smoothly.
With the optional Cirris AST Software, customize your testing procedures to match specific requirements. Test multiple parts simultaneously, manage pass/fail conditions efficiently, and integrate external instruments for expanded measurement ranges—all within a user-friendly interface.
The integrated Windows 11 PC ensures seamless connectivity with network systems, printers, and peripherals. Its 10.4” full-colour touchscreen provides intuitive control, while support for external monitors offers flexibility in various work environments.
Safety is paramount. The 5150 includes safety interlocks to protect operators during high-voltage tests. Additionally, internal sensors monitor temperature and humidity, ensuring optimal performance under varying environmental conditions.
www.combinedtestsolutions.co.uk/
