Latest Test and Measurement NewsJTAG Integration for Seica Flying Prober23 November 2023 - The successful partnership between GÖPEL electronic and Seica in the world of embedded JTAG solutions is growing: GÖPEL introduced the integration of the new PicoTAP ATE into the test systems from the Italian manufacturer Seica. The PicoTAP ATE controller provides a low-cost alternative for applications from basic boundary-scan test to processor-assisted test (VarioTAP) and FPGA-assisted test (ChipVORX). The compact and lightweight package enables simple installation right on a flying probe head of a Seica Pilot tester. The Flying Prober features the so-called FlyPOD, a compact probe block which can contact multiple test pads on the printed-circuit board assembly (PCBA) with a single probe movement. SIGLENT launched new Flagship Oscilloscope22 November 2023 - SIGLENT released the new flagship oscilloscope SDS7000A. SDS7000A provides 4 analog channels and 16 digital channels, with bandwidths of 3GHz and 4GHz, expanding design applications to new test requirements. The maximum sampling rate is 20GSa/s, the vertical resolution is 12-bit (by hardware), the standard acquisition memory depth is 500 Mpts per channel. This can be upgraded to 1 Gpts/ch. The noise floor is as low as 220μVrms at 4 GHz bandwidth. The waveform capture rate can go up to 1 million wfm/s, which speed up capturing abnormal events. The Scope has a 15.6-inch high-definition touch screen, which offers much space for analyzing various signals simultaneously and therefore help to improve the developers efficiency. Tabor opens Sales, Support, and Applications Center in Europe21 November 2023 - The office will be responsible for helping customers establish their signal sources needs primarily in the DACH region (Germany (D), Austria (A), and Switzerland (CH)). Elmar Neumann will head the DACH operation out of the new office, which is located in Schramberg in south-west Germany. Elmar brings to the company a rich history of RF Knowledge as well understanding of the Market in the D-A-CH Area. Debugger for Motor Control MCU Family from NXP20 November 2023 – The Universal Debug Engine (UDE) from PLS Programmierbare Logik & Systeme is now supporting the new S32M2 motor control solution from NXP Semiconductors. The S32M2 is a highly integrated solution that is optimized for efficiency improvements across body and comfort applications such as sunroof, pumps, fans, trunk openers and more, thus contributing to energy saving and range extension of electric vehicles, while offering in-cabin noise reduction and occupant comfort enhancement. OTA Measurements on IEEE 802.11be (Wi-Fi 7) Devices17 November 2023 – Anritsu and Bluetest combine their recent product upgrades to create an Over-the-Air (OTA) measurement solution for verifying RF performance in tri-frequency bands of the latest WLAN standard (IEEE 802.11be). This collaboration provides customers with a WLAN test solution capable of transmit power (TRP) and receive sensitivity (TIS) measurements on IEEE 802.11be supported devices. Measuring the OTA performance in life-like, but repeatable conditions, enables manufacturers of high-speed data transmission devices, including high-end smartphones, AR/VR devices and cloud gaming consoles, to optimize the radio performance and end-user satisfaction. Spectroradiometer for the UV, VIS and NIR Range16 November 2023 - JETI presents its latest product, the specbos 2501, a spectroradiometer that is characterized by its compact design and high measurement speed. JETI products offer the best system parameters in terms of stray light suppression and system stability in their class. The specbos 2501 relies on proven technologies with optimized and more powerful components from renowned manufacturers. Decisive innovations include an extended wavelength range from 200 to 1000 nm, a spectral resolution of 4 nm for the basic models and 2 nm for the high-resolution version (HiRes). Data is exchanged either via the USB-C, Bluetooth or LAN/PoE interfaces. A robust aluminium housing enables reliable measurement operation in industrial applications and harsh environments. Optimized In-line High Density In-Circuit Test System15 November 2023 - Keysight Technologies introduced the new Keysight i3070 Series 7i in-line test system, an automated in-circuit test system (ICT), offering increased capacity and throughput, that enables manufacturers to economically meet the complex test demands of larger node count printed circuit board assembly (PCBAs). The use of high-impedance nodes has been increasing as demand for signal quality, lower power consumption and improved functionality continues to grow. However, this also increases the duration of short tests, posing a challenge to testing efficiency. Testing high-speed PCBAs can be a time-consuming and daunting task, often requiring multiple cycles for comprehensive testing and slowing down manufacturing. More Articles ...
